DRIFTER – THE ONLY 100% AUSTRALIAN MADE DOUBLE FOLD CAMPER
Many Australian campers can trace their first camping memories back to family holidays in the iconic Cub Drifter. The 6-berth family off-roader first hit the scene in the 1970s and although production stopped in the late 1990s, their robust design and family-orientated setup with 2 large beds means that it’s not surprising that to this day, it’s not uncommon to see these ever-popular camper trailers pop up at campsites all around the country.
Building on what made the original Drifter such a success, as well as drawing inspiration from market demands for double-fold camper trailers, Cub Campers has brought the Drifter back with a brand new design. The Cub Drifter is a new generation of family camper trailer for the next generation of Aussie campers.
KEY FEATURES
- 2 x 4kg Gas Bottle & Holder
- 2 x 150ah Lithium Batteries
- 12” Electric Brakes
- 265/65R17 Goodyear Duratrac Tyres on 17″ 6 Stud Alloy Wheels
- 180L Water Capacity
- Battery Charger IC25RV (240V)
- Battery Charger IDC25X (12V)
- Extra Long 1400mm Pantry
- Fusion Stereo and Speakers
- Hot Water Included as Standard
- Independent Suspension
- King Size Bed with Cloud 9 Pillow Top Mattress
- Large Fridge Box & Slide with storage box
- LED Lights (internal & external)
- Light to Tow
- Microfibre Leather Lounge & Cushions in “Clay” x 4
- Quick & Easy to Set Up (The Ezy-Wind silent winch comes as standard)
- 12V DC-DC Charger
- LED Lights (internal & external)
- Large Fridge Box & Slide with storage box
- Microfibre Leather Lounge & Cushions in “Clay” x 4
STANDARD FEATURES & SPECIFICATIONS
- 12V Pump – 10L/min
- 240V External Inlet (15A)
- 240V External Outlet
- 240V Internal Double Outlet
- 265/65R17 Goodyear Duratrac Tyres on 17″ 6 Stud Alloy Wheels
- Twin Shock Absorbers (Set)
- Hand Pump on Drawbar
- LED Strip Lights (ACC Plug) 1.2 Metre
- LED Strip Lights (ACC Plug) 3.7 Metre
- Mains Pressure on Kitchen
- Medium Density Foam Double Mattress (2nd bed)
- Privacy Curtains x 2
- Rear Utility Rack
- Rear Wall Canvas with Window
- Roll Up Side Wall
- Truma Hot Water & Shower Unit
- Stonestopper Mud Flaps
- Window Weather Shield Kit
BODY SPECS
- Body Length – Body and Fridge Box only 3.68M
- Body Width – including Wheel Flares and fittings 2M
- Towing Height 1.71M
- Towing Length incl. Spare Wheel and Drawbar 5.60M
- Opened Out Length – incl. Drawbar and Rear Bed 6.60M
- Tare 1390kg ‡
- Ball Weight 145kg ‡
- ATM 1900kg
BRAKES & WHEELS
- AL-KO Square Axle: 50mm
- Brakes: 12” Electric
- Spare Wheel: Rear Mounted (Steel)
- Tyres: 265/65R17 Goodyear Duratrac
- Wheel Type: 17 x 8 Black Alloy (6/139.7 PCD)
CANVAS
- 100% Australian Made Tent Using Wax Converters Dynaproof Canvas: Grey
- Aluminium Awning Poles: Standard
- Deluxe Awning: Standard
- Internal Front Canvas Window & Zipper: Standard
- Plastic Bedside Windows Inc. Midge-Proof Fly Screen & Curtains: Standard
- Rear Wall Canvas With Window: Standard
- Roll Up Side Wall: Standard
- Window Weather Shield Set: 3
DRAWBAR
- 4kg Gas Bottle & Holder: 2
- Additional Clamp for AL-KO Jockey Wheel: Standard
- AL-KO Ball Hitch: 50mm Off Road
- AL-KO Jockey Wheel: 250mm
- Drawbar: 150 x 50 x 3.0mm
- Fridge Box and Slide: Standard
- Fridge Box Size: W=560mm L=930mm H=515mm
- Fridge Box Luggage Rack: Standard
- Galvanised Steel Stoneguard: Standard
- Jerry Can Holder: 2
- Silent Winch: Standard
- Stonestopper Mud Flaps: Standard
WATER
- 12V Pump: 10 L/min
- Hand Pump on Drawbar: Standard
- Locking Water Filler: Standard
- Truma Hot Water System & External Shower: Standard
- Water Gauge: Standard
- Water Tank: 180L
INSIDE FITTINGS
- Bedroom Privacy Screen: 2
- Bed Size Front: 2100 x 1600 x 135mm
- Mattress Front: Slumberest Cloud 9 Pillow Top
- Bed Size Rear: 1660 x 1370 x 90mm
- Mattress Rear: Medium Density Foam
- Dinette Table (Swivel Mounted) Converts Into Double Bed: Standard
- Seat Cushions: Microfibre Leather in “Flint”
- Corner Cushions: Standard
- Under Bed Storage: Standard
- Under Seat Storage: Standard
KITCHEN
- 1400mm Pantry: Standard
- Drawers: 2
- Ezy Clean Kitchen Top: Standard
- Mixer Tap: Standard
- Fold Out Shelf: Standard
- Smev Stainless Steel Stove & Sink: 3 Burner
OUTSIDE FITTINGS
- Roof Tie Down Points: Standard
- Slide Out Steps: Standard
- Utility Rack (Incl.Spare Wheel Bracket): Standard
POWER, LIGHT & AIR
- 240V External Inlet (15A): Standard
- 240V External Outlet: Standard
- 240V Internal Double Outlet: Standard
- 100AH Lithium Battery: 2
- Battery Charger IC25RV (240V): Standard
- Battery Charger IDC25X (12V): Standard
- 12V Accessory/USB Socket – DS Locker: Standard
- 12V External Outlet (ACC): 2
- 12V Internal Outlet (ACC): 3
- 12V Master Isolation Switch: Standard
- 12V Resettable Fuse for Fridge: Standard
- 12V Twin USB Socket: 3
- Fusion Stereo & Speakers: Standard
- LED Awning Light: Standard
- LED Bedside Lights: Standard
- LED Floor Lighting: Standard
- LED Kitchen Light (ACC Plug): 1
- LED Sensor Lights – DS Locker: 1
- LED Sensor Lights – Fridge Box: Standard
- LED Sensor Lights – Under Lounge: 2
- LED Strip Lights (ACC Plug) 1.2 Metre: 2
- LED Strip Lights (ACC Plug) 3.7 Metre: 1
- Solar Input (Anderson Plug) – Suits Unregulated Solar Panel: Standard
SUSPENSION & CHASSIS
- AL-KO Wind Down Legs: 4
- Australian Galvanised Steel Chassis: Standard
- Rear Recovery Points (2400kg Rating): Standard
- Shock Absorbers: Twin
- Suspension: Independent
All models specification are subject to change.
‡ The tare and ball weights are a guide only and will change depending on drawbar layout and accessories fitted to your camper. Please discuss with a member of the Cub sales team prior to purchase.
Build your own custom CUB
CALL US TODAY: 03 8727 6100
Below are our most popular options which have been combined into Cub Travel Packs that feature added value for less outlay.
Alternatively if you only want one or two options these can be added individually.
Packages:
OFF GRID PACK
- 2nd Water Tank (80L)
- 80L and 100L Water Tank Protectors
- 200ah Lithium Batteries x 2 (Upgrade from 1 x 100ah)
- 200W Redarc Folding Solar Panel Kit Inc. 5m Lead with Anderson Plug
- Utility Rack Number Plate Bracket
- Utility Rack Upgrade
- Utility Spare Wheel Bracket
TECHNOLOGY PACK
- 2000W Inverter
- Redarc BMS30
- Redarc RedVision TVMS
- Rearview Camera
XTREME OFF ROAD PACK
- 265/65R17 BFG KM3 M/T Tyres – Black Wheels X3
- Cruisemaster DO35 Hitch
- Increased ATM to 1950kg
ALL AVAILABLE OPTIONS
BRAKES & WHEELS
- Alloy 17 Inch Spare Wheel Upgrade
CANVAS
- 1/2 Long Wall Canvas with Door (Drawbar)
- 1/2 Long Wall Canvas with Window(Kitchen)
- 1/2 Long Wall Mesh (Kitchen)
- 1/2 Long Wall Mesh with Door (Drawbar)
- Draught Skirt
- Ezy Awning
- Front Wall Canvas with Window (Drawbar)
- Front Wall Mesh (Drawbar)
- Privacy Curtain – Mesh (Main Bed)
- Privacy Curtain – Mesh (Rear Bed)
- Rear (Kitchen) Wall Mesh
- Thermal Blanket
DRAWBAR
- Cruisemaster DO35 Coupling Upgrade
- Drawbar Extension Upgrade – 375mm
- Fridge Box Top Drawer (DS)
- Front Box Slide & Tray (DS)
KITCHEN & GAS
- Extra Gas Bayonet (PS Utilities Only)
- Side Shelf (Forward & Double Fold Series)
OUTSIDE FITTINGS
- Boat Loader Kit
- Rear Storage Box (Each)
- Utility Rack Bike Bracket
- Utility Rack Outboard Bracket
- Utility Rack Twin Jerry Can Bracket (Water Only)
POWER, LIGHT & AIR
- Redarc 2000W Inverter
- Redarc BMS 30 Upgrade
- Redarc RedVision Kit Upgrade
- TV Coaxial Outlet
SUSPENSION & CHASSIS
- Hot Dip Galvanise
WATER
- Smarttek Shower Tent
- Water Tank Protector (80L)
- Water Tank Protector (100L)
TRAVEL OPTION PACKS
-
- Off Grid Pack
- Techno Pack
- Xtreme Off Road Pack
POPULAR OPTIONS
- 1/2 Long Wall Canvas with Door (Drawbar)
- 1/2 Long Wall Canvas with Window (Kitchen)
- 1/2 Long Wall Mesh (Kitchen)
- 1/2 Long Wall Mesh with Door (Drawbar)
- Ezy Awning
- Front Wall Canvas with Window (Drawbar)
